Product DescriptionCompany Info.<>
- Brand:
- TR
- Principle:
- Vacuum filtration
- Style:
- Vertical type
- Applicable object:
- Lubricating oil
- Model:
- ZJD-J100
- Filter type:
- Fibre
- Performance:
- High efficiency filtration
- Rated flow:
- 6 m3/h
- Working pressure:
- 0.4 MPa
- Operating noise:
- 60-80 dB
- Inlet and outlet pipe diameter:
- 42 mm
- Deemulsification number:
- 15 min
- Cleanliness:
- 6-8 NAS
- Overall dimension:
- 1900*1300*2200 mm
- Effective filtration area:
- 6 ㎡
- Machine power:
- 76 kw
Applicable Scope：It is widely used in the fields of electric power, metallurgy, mining, machinery, chemical industry,communications, manufacturing, food stuff for purification or regeneration of hydraulic oil, shafting oil, refrigerator oil, machine oil, die-casting oil, air compressor oil, gear oil, heat treating oil, anti-wear hydraulic oil, emulsified oil, high water content oil ect. waste oil or contaminated oil, as well as injection molding oil, cylinder oil, textile knitting oil, high speed machinery oil, high precision lube oil.
Product AdvantagesThe dehydration system adopts three-dimensional three-dimensional flash evaporation technology to quickly remove the moisture and gas in the oil.
The heating system adopts optimized pipeline design to ensure uniform heating and stable oil temperature.
Precise filtration system, multi-stage filtration step by step encryption, large dirt holding capacity, can effectively remove impurities in the oil.
Automatic constant temperature control system, infrared liquid level control system, automatic pressure protection system and sophisticated configuration ensure the high-performance operation of the equipment.
The online oil filter can be unattended after it starts up normally, and the running status is displayed by the indicator light.
This machine has humanized design, low noise, easy operation, long maintenance interval, low energy consumption, and saving operating costs.
The whole machine is equipped with interlocking safety protection, and the oil inlet is interlocked with the heating system to avoid adverse effects caused by misoperation.
It is equipped with a reference reminder for filter replacement, and a shutdown device when the saturation pressure of the filter is too high.
Equipped with leakage and overload shutdown device to protect the motor.
Equipped with phase sequence, phase loss protection functions, and sudden shutdown safety mechanism.
