Product DescriptionCompany Info.<>
- Brand:
- TR
- Principle:
- Pressure filtration
- Style:
- Vertical type
- Applicable object:
- Lubricating oil
- Model:
- YL-B-J100
- Filter type:
- Filter element
- Performance:
- High efficiency filtration
- Rated flow:
- 3 m3/h
- Working pressure:
- 0.4 MPa
- Operating noise:
- 80 dB
- Inlet and outlet pipe diameter:
- 42 mm
- Cleanliness:
- 7-8 NAS
- Overall dimension:
- 700*450*850 mm
- Effective filtration area:
- 5 ㎡
- Machine power:
- 2.2 kw
purifier hydraulic oil machine high precision oil purifier manufacturer
Specifications
- three filter elements for removing impurities quickly
-Good performance
-High ReputationApplication:
Series YL portable oil purifier mainly deal with unqualified insulating oil, turbine oil, lubricating oil etc., this machine can do precision filtering, it usually equips three-stage filters, also can equip four or five stage filters as per user's requirements. Light weight, easy operation, it can be used as oiling machine for long distance and high-lift oiling works.
Features:
1. Use patented technology to produce. Such as high-effective separating separation tower, fuzzy control technology, dewatering and degassing very effectively.
2. It can purify the losing-efficient insulation oil and make the oil reach the new oil standard without power cut, changing the oil or using filtering papers.
3. Have the function of filling oil under vacuum condition.
4. Solve the problem of removing the acetylene.
5. The purifier has large route, strong capability of holding dirt and can be used for a long time.
6. This machine is small, light weight and convenient.
7. The ultrasonic cleaning function can be selected.
8. Have the multi-functions of centrifugal separation, molecular filter, condension de-watering and vacuum dry.
9. Have the functions of automatic burning protection and elimination foam.
10. Operate steady and the noise is specially low.
Technical Parameter of Oil Filter Purification System
Index YL-B-30 YL-B-50 YL-B-75 YL-B-100 YL-B-150 YL-B-200 YL-B-250 YL-B-300 (L/H)
Capacity
1800 3000 4800 6000 9000 12000 15000 18000 (m)
Lift distance
6 8 8 10 12 15 15 15 Filtration precision 5 µm( or design according to requirement) Working pressure ≤0.4 MPa kW
Power consumption
0.75 0.75 1.5 2.2 3 4 4 5 mm
Diameter of oil pipe
25 25 32 40 50 50 60 60 Power supply 380V/50HZ/3 phases(or design according to requirement) Kg
Weight
78 82 105 135 150 180 225 265 dimension Length
mm
700 720 850 900 1100 1150 1200 1250 Width
mm
350 400 700 750 900 900 950 1000 Height
mm
900 900 950 950 1050 1050 1100 1100
