Product DescriptionCompany Info.<>
- Brand:
- TR
- Principle:
- Adsorption method
- Style:
- Vertical type
- Applicable object:
- Lubricating oil
- Model:
- NRY-J1
- Filter type:
- Fibre
- Performance:
- High efficiency filtration
- Rated flow:
- 1 m3/h
- Working pressure:
- 0.4 MPa
- Operating noise:
- 60-80 dB
- Inlet and outlet pipe diameter:
- 25 mm
- Deemulsification number:
- 15 min
- Cleanliness:
- 6-8 NAS
- Overall dimension:
- 1900*1300*2200 mm
- Effective filtration area:
- 6 ㎡
- Machine power:
- 33 kw
High efficient Black engine oil bleaching ship oil decoloring recycling machine
Usage:
NRY Engine Oil Recycling machine is particularly suitable to regenerate used internal-combustion engine oil including diesel engine oil, gasoline engine oil and used hydraulic oil, other used machinery lubrication oil into clean yellow base oil. If your black oil want to recover the color into yellow, then you can choose it. Our NRYseries machine is at low price and easy operation. NRY series are able to effectively remove colloid, oxid, acid, pitch, particles, impurities, water, gas in the used oil. Specially, NRY can restore the color of used oil and remove the scent rapidly.
Features:
1.This oil purifier used a physiochemical reaction to eliminate the electric charge between polar particulate in waste oil, which is gathered into coarse particles and removed, it is also can separate colloid, bitumen and other compound. Under high vacuum and high temperature situation the harmful gas and the water content can be removed by the deodorization and dehydration system, aiming to purify waste oil and retain the active ingredient from oil.
2. High precision stainless steel net is used, which is anti-corrosive, high temperature resistant and has a good mechanical strength and long lifetime. The pressure filter that easy to operate and economical, is used as filter medium.
3. It has a novel structure and reasonable layout, it is deemed as a "mini refinery".
4. The processing effect is obvious and the decolorization effect is straightforward, besides, it can also serve for multiple purposes.
Technical Specification:
Technical data
Item
Unit
NRY-SS
NRY-S
NRY-I
NRY-II
NRY-III
NRY-IV
NRY-V
NRY-VI
NRY-VII
NRY-VIII
NRY-IX
Capacity
Kg/d
500
1000
2000
4000
6000
8000
10000
12000
15000
20000
25000
Recovery rate
%
75~95(Depending on the used oil property)
Temperature Range
℃
140
Working pressure
Mpa
0.2~0.5
Working noise
dB(A
65~80
Power supply
380V/50HZ(customized)
heating power
KW
30
63
96
144
168
252
288
384
480
576
672
Total power
KW
35
75
108
162
186
284
320
424
528
636
740
Why oil recycling machines are needed?
Facing continuous increase in oil consumption, waste oil recycling has become more attention in the world, However, the use oftraditional oil refining technology, which remains common and popular, has been under criticism for many reasons. Firstly, the outputs cannot be used directly and quickly change to black colour or create bad smell. Secondly, traditional machine is harmful to environment as it creates waste residue and bad smelling.Now our company can provide you the NRY used oil purifier machine, which can quickly remove water,dirty particles,suspend impurities and change the colorto yellow.
